Description
🔧 General Specifications
| Feature | Specification |
|---|---|
| Display | 5999-count LCD |
| Auto Range | Yes |
| True RMS | Yes |
| Backlight | Yes |
| Flashlight | Yes (rear) |
| Data Hold | Yes |
| Max/Min Hold | Yes |
| Relative Measurement | Yes |
| Auto Power Off | Yes (after ~15-17 min) |
| Power Source | 2 × AAA 1.5V batteries |
| Dimensions | Approx. 140 × 70 × 30 mm |
| Weight | Approx. 200 g |
📏 Measurement Ranges
| Function | Range | Accuracy |
|---|---|---|
| DC Voltage | 0.1 mV – 1000 V | ±(0.5% + 3) |
| AC Voltage | 0.1 mV – 750 V | ±(1.0% + 5) |
| DC Current | 0.1 μA – 10 A | ±(1.0% + 3) |
| AC Current | 0.1 μA – 10 A | ±(1.2% + 5) |
| Resistance | 0.1 Ω – 60 MΩ | ±(1.0% + 3) |
| Capacitance | 10 nF – 100 mF | ±(4.0% + 5) |
| Frequency | 10 Hz – 10 MHz | ±(0.1% + 3) |
| Duty Cycle | 0.1% – 99.9% | ±(1.2% + 2) |
| Temperature | -20 °C to 1000 °C (K-type) | ±(1.0% + 5) |
| Diode Test | Yes | – |
| Continuity | Yes (buzzer < 50 Ω) | – |
| NCV (Non-contact voltage) | Yes | With LED/beep warning |
🔌 Input Protection
-
Fuse: 10A/250V fuse for current ranges.
-
Input Protection: PTC protection for resistance/capacitance/frequency.
-
Input Limit: 1000V DC / 750V AC max.
-
Category Ratings: Marked CAT III 600V
