YIHUA 813 Portable 3 Machines Combination Repair Set Phone Laptop Repair DC Power Supply Hot Air Soldering Work Station

YIHUA 1505D-IV or YIHUA 3005D-IV

[Multiple Protections] The dc power supply can produce highly regulated voltage with low ripple. Supports sophisticated over-voltage protection, over-current protection, overload protection, over-temperature protection, and current cut-off protection.
[Adjustable Output Voltage Range] 0-5V/0-15V (YIHUA 1505D-IV) or 0-30V (YIHUA 3005D-IV), settings to fit your mission needs.
[4-Digits LED Display] Support 4-digits display provides a more accurate and clear date for the voltage and current value, it can read easily in a low light environment. This bench power supply is highly efficient with a high power capacity and relatively low noise.

Technical Data:

YIHUA 939D+-IV (90W) soldering station

Inner box: 25.8*22.3*18 cm

Unit weight: 2.83 KGS/PCS

Rate power: 42W (Max. 180W)

Soldering iron heater: 90W ceramic heating core

Soldering iron temp. range: 200~480 ℃

YIHUA 993DM-IV hot air station

Inner box: 32.5*30.5*18 cm

Unit weight: 4.53 KGS/PCS

Rate power: 1000W

Hot air gun heater: Skeleton type ceramic heating core

Hot air temp. range: 100~500 ℃

Airflow: ≤120L/min (Max.)

Air delivery: compressor motor

YIHUA 1505D-IV DC power supply

Inner box: 29.5*14.5*18 cm

Unit weight: 1.93 KGS/PCS

Rate power: 120W

Output power: 75W

Output voltage: DC 0~5V/0~15V

Output current: DC 0~5A

Load regulation: <0.2%+3mv
Ripple & noise: Vrms<0.2%(10Hz-1MHz)
Current protection: 0~5A
Output voltage (USB): DC 5V/9V/12V±0.2V
Output power (USB): 20W
Voltage precision (USB): 0.1V
Current Precision (USB): 0.4%+10mA
Current Protection (USB): 4A/2.5A/2A

YIHUA 3005D-IV DC power supply

Inner box: 29.5*14.5*18 cm

Unit weight: 1.93 KGS/PCS

Rate power: 220W

Output power: 150W

Output voltage: DC 0~5V/0~30V

Output current: DC 0~5A

Load regulation: <0.5%+3mv
Ripple & noise: Vrms<0.2%(10Hz-1MHz)
Current protection: 0~5A
Output voltage (USB): DC 5V/9V/12V±0.2V
Output power (USB): 20W
Voltage precision (USB): 0.1V
Current Precision (USB): 0.4%+10mA
Current Protection (USB): 4A/2.5A/2A
