WinAPEX ET8201 Auto-Range AC Digital Clamp Meter

SKU: ET8201

4,200.00

20 People watching this product now!

Payment Methods:

payment-methods

Description



📋 WinAPEX ET8201 Clamp Meter – Full Specifications

🔧 General

  • Type: Digital Clamp Meter (Auto-Range)

  • Display Count: 5999 counts

  • Measurement Mode: True RMS

  • Display Rate: Approx. 3 times/sec

  • Jaw Opening: 55 mm

  • Power Supply: 2× AAA batteries (1.5 V each)

  • Dimensions: 176 × 67 × 33 mm

  • Weight: Approx. 300 g


Electrical Measurement Ranges

Parameter Range Accuracy
DC Voltage 0.1 mV – 700 V ±(0.5% + 3)
AC Voltage 0.1 mV – 750 V ±(0.8% + 10)
DC Current 0.1 A – 600 A ±(2.5% + 30)
AC Current 0.1 A – 600 A ±(2.5% + 30)
Resistance 0.1 Ω – 60 MΩ ±(1.2% + 3)
Capacitance 1 nF – 60 mF ±(4.0% + 5)
Temperature -20°C to 1000°C (probe) ±(1.0% + 3°C)
Frequency Not specified
Diode Test Yes ~2V max test voltage
Continuity Test Yes Buzzer if < 50 Ω

🧰 Other Functions

  • True RMS: Yes

  • Auto Range: Yes

  • NCV (Non-Contact Voltage): Yes, with alert

  • Data Hold: Yes

  • Backlight Display: Yes

  • Flashlight/Torch: Yes

  • Auto Power Off: Yes

  • Overload Protection: Yes

  • Battery Low Indication: Yes

  • Relative Mode: No

  • MAX/MIN Hold: No

  • Frequency/Duty Cycle: Not included


🧳 Included Accessories

  • Test leads

  • K-type thermocouple temperature probe

  • Zippered soft bag

  • User manual
