WinAPEX ET8101 Professional Digital Multimeter
Original price was: ₨3,000.00.₨2,600.00Current price is: ₨2,600.00.
Payment Methods:
Description
🔧 Technical Specifications
📟 Display
-
Type: Large LCD with backlight
-
Count: 5999 (5 5/6 digits)
-
Backlight: Yes, with auto-off
-
Analog Bar Graph: No
⚡ Voltage Measurement
| Parameter | Range | Accuracy |
|---|---|---|
| DC Voltage | 0.1 mV – 1000 V | ±(0.5%+3) |
| AC Voltage (True RMS) | 0.1 mV – 750 V | ±(0.8%+5) |
🔌 Current Measurement
| Parameter | Range | Accuracy |
|---|---|---|
| DC Current | 0.1 μA – 10 A | ±(1.0%+3) |
| AC Current (True RMS) | 0.1 μA – 10 A | ±(1.5%+5) |
📏 Resistance / Capacitance / Frequency
| Function | Range | Accuracy |
|---|---|---|
| Resistance | 0.1 Ω – 40 MΩ | ±(1.0%+3) |
| Capacitance | 1 nF – 30 mF | ±(4.0%+5) |
| Frequency | 10 Hz – 10 MHz | ±(0.1%+3) |
| Duty Cycle | 0.1% – 99.9% | ±(1.0%+2) |
🧪 Other Functions
-
Diode Test: Yes
-
Continuity Buzzer: Yes (with <50 Ω detection)
-
Non-Contact Voltage Detection (NCV): Yes
-
Live Wire Detection: Yes
-
Data Hold / Max Hold: Yes
-
Relative Measurement: Yes
-
Auto Power Off: After ~15 minutes (can be disabled)
-
Backlight Auto-Off: After ~15 seconds
🔋 Power & Build
-
Battery: 2 × AAA (1.5 V)
-
Low Battery Indication: Yes
-
Case: ABS plastic with protective rubber sleeve
-
Stand: Flip-out kickstand
-
Probes: Standard CAT III-rated test leads
🔒 Safety & Standards
-
Safety Rating: IEC 61010-1, CAT III 600 V
-
Input Protection: Fuse & overload protection on all ranges
-
Fuse Ratings:
-
mA: F200mA/250V
-
A: F10A/250V
-
