UNI-T UT18B MAX Which Is A True RMS Meter With 6000 Counts Digital Multimeter
-
Display: Large LCD showing 6000 count resolution with backlight.
-
Auto Range: Automatically selects the measurement range.
-
True RMS: Measures true root mean square for accurate readings on non-sinusoidal AC signals.
₨19,500.00
11
People watching this product now!
Payment Methods:
Description
| Feature | Specification |
|---|---|
| Display Count | 6000 counts |
| True RMS | Yes |
| Auto/Manual Range | Auto and Manual |
| Sampling Rate | 3 times per second |
| Data Hold | Yes |
| Relative Mode | Yes |
| Max Display | 5999 |
| Backlight | Yes |
| LED Flashlight | Yes |
| Low Battery Indication | Yes |
| Input Protection | Yes (Fused) |
| Input Impedance | ≥10MΩ (VDC/VAC) |
| Power Supply | 2 × 1.5V AA batteries |
| Dimensions | Approx. 195 × 92 × 55 mm |
| Weight | Approx. 400g |
| Function | Range | Accuracy |
|---|---|---|
| DC Voltage | 600mV – 1000V | ±(0.5% + 3) |
| AC Voltage (True RMS) | 600mV – 750V | ±(0.8% + 3) |
| DC Current | 600µA – 10A | ±(1.0% + 3) to ±(2.0% + 5) |
| AC Current (True RMS) | 600µA – 10A | ±(1.5% + 3) to ±(2.5% + 5) |
| Resistance | 600Ω – 60MΩ | ±(0.8% + 2) |
| Capacitance | 10nF – 100mF | ±(3.5% + 5) |
| Frequency | 10Hz – 10MHz | ±(0.1% + 3) |
| Temperature | -40°C to 1000°C | ±(1.0% + 3) |
| Diode Test | Yes (with display of voltage drop) | |
| Continuity Test | Yes (with buzzer) | |
| LED Test | Yes (up to 5mA current) | |
| VFD Mode | Yes (for motor drive systems) |
-
CAT III 600V
-
CAT II 1000V
-
Fuses:
-
10A, 1000V fuse for high current input
-
600mA, 1000V fuse for mA/µA input
-
📦 Special Features
-
NCV (Non-Contact Voltage Detection): No
-
VFD Mode: Yes, to measure accurate voltage on motor drives
-
LED Test Mode: Built-in feature for testing LEDs directly
