TOOLTOP X6 Smart 400A AC DC Clamp Meter 6000 Counts Ammeter Voltmeter Auto + Manual Test Hz Capacitance NCV Ohm Diode Testers

Features:

Support up to 400A AC and DC current measurement to meet a wider range of current measurement needs.

Dual color screen design which can simultaneously display more measurement information, improving user convenience and information display effect.

Automatic identification and measurement of various electrical parameters: capable of automatically identifying and measuring resistance, AC/DC voltage, AC current, on/off, and frequency, simplifying the measurement process and improving work efficiency.

Dual measurement mode: supports both manual and automatic measurement modes to meet the usage habits and measurement needs of different users.

Multifunctionality: The product has multiple measurement functions, including AC current, DC current, AC voltage, DC voltage, resistance, diode, capacitor, temperature, and frequency.

The maximum allowable voltage between the measurement end and the ground is 600V DC or 600V AC

Full range overload protection.

Specifications:

Parameters | Measurement Range | Resolution | Accuracy

AC current: 40A, 400A | 0.01A, 0.1A | ± (2.5% reading+30 digits)

DC current: 40A, 400A | 0.01A, 0.1A | ± (2.5% reading+30 digits)

DC voltage: 600V, 600mV | 0.1V, 0.01mV | ± 0.5% reading + 3 digits

AC voltage: 600V, 600mV | 0.01V, 0.01mV | ± 0.8% reading + 5 digits

Resistance: 600Ω-60MΩ | 0.1Ω-0.01M Ω | ± 0.8% reading+3 digits

Temperature: -40℃~999℃, -40℉~1832℉| 1℃, 1℉|±(1.0%+3) reading

Frequency: 60.0Hz, 1000Hz | 0.1Hz, 1Hz | ± (1.0% reading+5 digits)

Capacitance: 6nF -60mF | 0.1nF -0.01mF | ± (10% reading+40 digits), ± (2.5% reading+20 digits)

Diode test: 1V | 0.001V | Test current: about 1mA, open circuit voltage: about 3.2V. The display shows an approximate value of the forward voltage drop of the diode

On/off Test: Support

Display: LCD

Maximum display value: 6000 digits

Polarity indication: Automatic indication, “-” indicates negative polarity.

Over range display: “0L” or -0L “.

Sampling time: approximately 3 times/second

Unit display: With functions and power unit display

Automatic shutdown time: 15 minutes

Power supply: 1.5V AAA battery x2（not included）

Battery under voltage indication: LCD display symbol

Working height: maximum 2000m

Working temperature: 0℃~40℃

Storage temperature: -20℃~60℃
