RF4 RF-6565PRO High Performance 6.5X to 65X Trinocular Stereo Microscope
SKU:
RF-6565PRO
₨88,000.00 Original price was: ₨88,000.00.₨83,000.00Current price is: ₨83,000.00.
17
People watching this product now!
Payment Methods:

Description
🔧 Optical Specifications
Feature | Specification |
---|---|
Eyepieces | Wide Field WF10X/22 or WF10X/23 |
Objective Zoom Range | 0.65X – 6.5X |
Total Magnification | 6.5X – 65X (standard); extendable with auxiliary lenses |
Zoom Ratio | 10:1 |
Viewing Head | Trinocular (45° inclined, 360° rotatable) |
Interpupillary Distance | 54mm – 76mm |
Diopter Adjustment | ±5 on both eyepieces |
📸 Trinocular Port (Camera Integration)
Feature | Specification |
---|---|
CTV Adapter | 0.5X C-mount adapter included |
Camera Support | Supports digital/USB/HDMI cameras |
Synchronous Zoom | Zoom level is identical in eyepiece & camera |
💡 Illumination
Feature | Specification |
---|---|
Light Source | 144 LED ring light |
Brightness | Adjustable (with dimmer control) |
Light Type | White LED, shadow-free |
Power Supply | 100V–240V (AC adapter included) |
🛠️ Mechanical & Structural
Feature | Specification |
---|---|
Stand Type | B3 Aluminum Alloy Base |
Lifting Range | 50mm |
Working Distance | 110mm (standard), extendable |
Head Rotation | 360° |
Base Plate Size | ~200mm x 255mm (varies by model) |
Column Diameter | Φ32mm |
Lens Mount Diameter | Φ76mm |
Center Distance | 155mm |
📦 Included in the Box
-
Trinocular microscope head
-
WF10X eyepieces (pair)
-
0.5X CTV camera adapter
-
144 LED ring light with controller
-
B3 Aluminum alloy base
-
Dust cover, tools, and user manual
